Wall Ties

Thor Helical 9mm Remedial Wall Ties offer rapid wall tie replacement and reliable brick pinning installation. 316 grade stainless steel helical ties are the recommended choice for tying masonry walls. The SDS drive tool which holds and hammer-drives the wall ties permits safer controlled installation of CDTies.

Self-tapping replacement wall ties have a 9mm diameter and are manufactured with patented precise pitch engineering. They screw into brick, masonry, concrete and timber when hammered into

Used to re-connect and reinforce separating masonry layers. This brick reinforcement can be used to tie perimeter walls of a structure to cross walls, pin rubble filled walls or stitch masonry arch layers in buildings, bridges and tunnels.

Polymer modified grout is pumped into long pre-formed holes. Stainless steel helical pins are wound into the unset grout. Once set, the high strength grout interlocks with the peaks and troughs of the helix to bond the brick pins to the masonry.

Lateral restraint ties restrain bowing walls by connecting masonry façades to parallel structural timbers. The 8mm ties have a drill-bit tip that cuts into softwood joists, driven through two or more for anchoring.
Installed externally with minimal disruption, few floorboards are lifted to locate joists and avoid wires/pipes. A 14mm clearance hole is drilled in the façade, and the tie is driven using a setting tool that drills and screws. Resin secures the masonry connection to restrain the wall
